The PILOT is a platform style trunk rack that fits most cars without the need of a towing system. Safely fits 2 bikes without having them moving or touching each other which prevents scratches to the bikes.

•

  FRAME

  The geometry of the PILOT frame allows a quick and easy installation on most cars.
  Solidly built of steel and high impact resistant plastic materials.
  The geometry keeps the bikes away from the car.

•

  QUICK INSTALLATION

  Using the plastic hubs, you can adjust, fold or unfold the rack in no time.

•

  LOCKING CLAMPS

  The clamps are big enough to fit most bike frames.
  Made of reinforced Nylon, the clamps are highly resistant.
  An integrated pad prevents scratching the bike paint and allow most brakes cables to go through.
  Each clamp is equipped with a locking knob.

•

  WHEEL SUPPORTS

  The wheel holders will accommodate all wheelbases, even very small children’s bikes.
  The straps allow a secure attachment of the wheels and the pads protect the rims.
  The straps are long enough to hold the biggest rims.

•

  SAFETY

  The product is supplied with an additional safety strap that allows to secure the bike.

•

  HOOKS

  All the hooks have a protective coating that prevent them from damaging the car paint.

•

  SIZE

  If you don’t carry any bike, you can always fold the platform which might be convenient for parking.

TECHNICAL SPECIFICATIONS

Max number of bikes: 2
Dimensions (folded): 99 x 92 x 23 cm
Weight: 9kg
Max load capacity: 30kg
Max weight per bike: 15kg
Integrated lighting board: no
Locking: bikes to the rack

The carrier cannot be mounted to cars that have a plastic spoiler.
